--- title: "Satellite Imagery with RTL-SDR and GOES 16" date: 2025-06-08 draft: false description: "Receiving full disk images of the Earth from GOES 16 with an RTL-SDR and a 2.4 GHz Parabolic Grid Antenna" categories: Electronics tags: [Raspberry Pi, SDR] --- Receiving full disk images of the Earth from GOES 16 with an RTL-SDR and a 2.4 GHz Parabolic Grid Antenna. {{< alert >}} **Heads up!** This article was originally posted on my old website in April of 2019. While the general process of receiving images from GOES 16 won't have changed, the software tools may have evolved since then. Make sure to read the documentation for `goestools` and don't copy and paste any terminal commands below without fully understanding what you're asking for! {{< /alert >}} ## Introduction After stumbling upon the online communities around software defined radio (mainly the [RTL-SDR Blog](https://www.rtl-sdr.com/) and the [RTL-SDR subreddit](https://www.reddit.com/r/rtlsdr/)), I discovered it was possible to receive high resolution, full disk images of the Earth from NOAA's [GOES](https://en.wikipedia.org/wiki/Geostationary_Operational_Environmental_Satellite) satellites using cheap and simple (relative to most other satcom systems) hardware setup. Since I'm located in the Northeastern United States, I've got a pretty good view of [GOES-16](https://en.wikipedia.org/wiki/GOES-16), so I decided to see if I could actually manage to set up a receiver. ## Hardware Based on a few guides I found online (see Notes below), I determined that I needed the following hardware: 1. Raspberry Pi 3B+. 2. An RTL-SDR software-defined radio dongle. Photograph of a Raspberry Pi single board computer with an RTL-SDR software-defined radio attached.

Photograph of a Raspberry Pi single board computer with an RTL-SDR software-defined radio attached.

3. A low noise amplifier (LNA) and SAW filter designed for the frequency that the GOES satellite uses (around 1.7 GHz). I used the [SAWbird+ GOES Barebones from Nooelec](https://www.nooelec.com/store/sawbird-plus-goes.html). 4. A 2.4 GHz parabolic grid antenna [modified for 1.7 GHz](https://www.reddit.com/r/RTLSDR/comments/9ahdzc/modification_of_wifi_grid_antenna_to_make_it_work/). Photograph of a satellite dish mounted on a tripod pointing towards the sky.

Photograph of a satellite dish mounted on a tripod pointing towards the sky.

5. Various RF adapters and coaxial cables needed to connect everything together (depends on the specific setup, see Notes below). Photograph of a satellite dish showing it connected to the RTL-SDR dongle via a coaxial cable.

Photograph of a satellite dish showing it connected to the RTL-SDR dongle via a coaxial cable.

## Software To setup the software side of things, I followed [lxe's guide](https://gist.github.com/lxe/c1756ca659c3b78414149a3ea723eae2), summarized below. > Prep your Raspberry Pi and install necessary drivers and software. > > **0. Get your Raspberry Pi ready** > > - Download [Raspbian Lite Image](https://www.raspberrypi.org/downloads/raspbian/) and [Etcher](https://etcher.io/) > - Use Etcher to write the image to the SD card. > - Mount the SD card as a volume on your machine. > - Follow [this procedure](https://www.raspberrypi.org/forums/viewtopic.php?t=191252) to configure WiFi and SSH. > - Plug the card into your Raspberry Pi and turn it on. > - Find the IP address of the Raspberry Pi using your gateway/router administrative interface. > > Now you can SSH into your Raspberry PI as `pi` with a default password `raspberry`. > > **1. Get everything up to date** > > From now on all commands should be run on the Raspberry Pi. > > ```bash > sudo apt update > sudo apt dist-upgrade > sudo reboot > ``` > > **2. Install dependencies** > > ```bash > sudo apt install git build-essential cmake libusb-1.0 libopencv-dev libproj-dev > ``` > > **3. Install `librtlsdr`** > > Grab the latest [librtlsdr](https://github.com/steve-m/librtlsdr.git) source, compile it, and install the shared libraries/includes. > > ```bash > git clone https://github.com/steve-m/librtlsdr.git > cd librtlsdr > mkdir build > cd build > cmake -DCMAKE_INSTALL_PREFIX:PATH=/usr -DINSTALL_UDEV_RULES=ON .. > sudo make -j2 install > > sudo cp ../rtl-sdr.rules /etc/udev/rules.d/ > sudo ldconfig > echo 'blacklist dvb_usb_rtl28xxu' | sudo tee --append /etc/modprobe.d/blacklist-dvb_usb_rtl28xxu.conf > > sudo reboot > ``` > > **4. Test your the RTL-SDR dongle** > > ```bash > rtl_test > ``` > > You should see something like this: > > ``` > Found 1 device(s): > 0: Realtek, RTL2838UHIDIR, SN: 00000001 > ... > ``` > > If it hangs, just press Ctrl + C to exit. It doesn't have to finish. > > If there are errors, or if the device is not recognized: > > - Reinstall the driver from Step 3 > - Ensure the dongle is secured in the USB port > - Remove all USB hubs and plug in into the Pi directly > - Make sure you power your Raspberry Pi with at least a 2.5A power supply > - Check the device using `lsusb` command. You should see `ID 0bda:2838 Realtek Semiconductor Corp. RTL2838` or something of the like listed there. If not, try the previous steps. > - Run `dmesg` and check for errors such as `error -71` related to the USB device. This may mean that your RTL-SDR receiver might be broken. This happened to me, so I ordered another one, which ran fine. > > **5. Install [`goestools`](https://github.com/pietern/goestools.git)** > > ```bash > git clone https://github.com/pietern/goestools.git > cd goestools > git submodule init > git submodule update --recursive > mkdir build > cd build > cmake -DCMAKE_INSTALL_PREFIX:PATH=/usr .. > > sudo make -j2 install > ``` > > **6. Create `goesrecv.conf` config** > > ```bash > cat < ~/goesrecv.conf > [demodulator] > mode = "hrit" > source = "rtlsdr" > > [rtlsdr] > frequency = 1694100000 > sample_rate = 2400000 > gain = 5 > bias_tee = false > > [costas] > max_deviation = 200e3 > > [decoder.packet_publisher] > bind = "tcp://0.0.0.0:5004" > send_buffer = 1048576 > > [monitor] > statsd_address = "udp4://localhost:8125" > EOF > ``` > > If you're using a NooElec SmarTee dongle with an always-on bias tee, or if you're powering your SAWBird through the micro USB port, set `bias_tee = false` under `[rtlsdr]`. > > If you're using RTL-SDR.com dongle, set `bias_tee = true` to power the SAWBird board. > > **7. Roughly point your antenna at the satellite** > > Find where the GOES-16 or GOES-17 satellites are in the sky at your location using [agsattrack.com](http://www.agsattrack.com/). > > Note the **azimuth** and **elevation**. > > Use an **actual real compass** to point your dish at the azimuth. I've been using the iPhone phone compass, which has a 20-30 degree error, rendering it practically useless. > > Adjust your dish angle according to the elevation. > > **8. Run goesrecv and perform fine antenna adjustments** > > ```bash > goesrecv -v -i 1 -c ~/goesrecv.conf > ``` > > This will show output every second that looks something like this: > > ``` > ... > 2018-09-15T21:52:03Z [monitor] gain: 8.44, freq: -2121.4, omega: 2.589, vit(avg): 2400, rs(sum): 0, packets: 0, drops: 55 > ``` > > The `vit(avg)` stat shows the average [viterbi error rate](https://en.wikipedia.org/wiki/Viterbi_error_rate) over 1 second interval (if running with `-i 1`). > > If there's no signal, the `vit` value should be over 2000. When signal is stronger it should decrease. > > This should help you point the antenna correctly. Slightly rotate the dish right or left and note whether the `vit` errors are increasing or decreasing. > > Once you're at the local error minimum, perform the same process to find the minimum error rate while slightly adjusting the vertical angle. > > When the `vit` errors are at their lowest, you've pointed the antenna. Double check the antenna position again with a compass to make sure you're pointed at the intended satellite; GOES-17 and GOES-16 are only about 15 degrees from each other in the sky. > > **9. Restart `goesrecv` and play around with the config parameters.** > > If your `vit` errors are under 400, and you're observing no packet drops, you're all set! > > If the average errors are at around 1500–1800, try the following: > > - Terminate and restart `goesrecv`. This should allow it to readjust the gain and frequency offset to get a better read on the signal. > > - Cool the Raspberry Pi and the RTL-SDR dongle. I've noticed that temperature might significantly affect reception quality. > > - Play around with `goesrecv.conf` parameters. Try adjusting the `gain` and `sample_rate`. For the NooElec XTR or other E4000 tuners, you might need to set your gain to `10` or below. > > Once you decreased the error rates, but your `vit` is still over 400, try making very slight adjustments to the antenna again. > > **10. Process packets into images** > > While `goesrecv` is running, in a separate session, run: > > ```bash > goesproc -c /usr/share/goestools/goesproc-goesr.conf -m packet --subscribe tcp://127.0.0.1:5004 > ``` > > Once `goesproc` receives enough packets, it will start writing images and text to the locations described in `/usr/share/goestools/goesproc-goesr.conf`. > > ``` > Writing: ./goes16/m2/ch13/2018-09-15/GOES16_M2_CH13_20180915T231750Z.jpg > Writing: ./goes16/m2/ch13_enhanced/2018-09-15/GOES16_M2_CH13_enhanced_20180915T231750Z.jpg > Writing: ./goes16/m2/ch02/2018-09-15/GOES16_M2_CH02_20180915T231750Z.jpg > Writing: ./goes16/m2/fc/2018-09-15/GOES16_M2_FC_20180915T231750Z.jpg > Writing: ./goes16/m1/ch07/2018-09-15/GOES16_M1_CH07_20180915T231820Z.jpg > ... > ``` ## Results Here are some of the images I was able to get off of GOES 16: {{< gallery >}} False color image from GOES 16, cropped to show full resolution.

False color image from GOES 16, cropped to show full resolution.

Full disk image of the Earth received from GOES 16 Channel 7.

Colorful full disk image received from GOES 16. Enhanced with software post processing.

{{< /gallery >}} ## Notes This wouldn't have been possible without the work of a lot of others before me. Some of the most useful resources I found about this subject are: * Pieter Noordhuis' [goestools](https://github.com/pietern/goestools) and his guide for setting up [A minimal LRIT/HRIT receiver](https://pietern.github.io/goestools/guides/minimal_receiver.html) * This [guide](https://gist.github.com/lxe/c1756ca659c3b78414149a3ea723eae2) that goes into a little more detail about how to use goestools. * Additionally the [RTL-SDR Blog](https://www.rtl-sdr.com/) is a wealth of knowledge about anything to do with this type of software defined radio.
